Used Cushion Tire Forklift Rialto - Forklift trucks are commonly classified by the kind of work they complete as well as the kind of tire they use. There are two main kinds of tire classification for forklifts, pneumatic and cushion tire.
There are drawbacks and benefits to both pneumatic and cushion forklift tire options. The cushion tire benefits and drawbacks can only be understood in the context of what the pneumatic tire offers in terms of forklift operation.
Forklift Tire Classifications
Cushion Tires
Cushion tires are made up of either smooth or treaded solid rubber and are designed around a metal ring or baseband. These kinds of forklift tires are cheaper to make and easier to maintain. Cushion tires are designed for smooth surface applications such as work that takes place mostly indoors or around loading docks. Cushion tires are also better suited to applications in tight spaces. This is because they offer a turning radius that allows for movement around tight corners. Forklifts that use cushion tires can be lower to the ground compared to pneumatic tire models and the increase in vertical clearance is welcome for many applications. Pneumatic tires provide better traction compared to cushion tires; especially on wet surfaces and outdoor locations.
There are many jobs suitable for cushion tire forklifts such as unloading shipments, transporting items to and from the loading areas, order picking, unloading inventory and more.
Pneumatic Tires
Pneumatic tires, on the other hand, are primarily designed to operate in rougher terrain, with uneven surfaces. These tires have two categorizations:
The solid resilient pneumatic tires are comprised entirely of rubber and the standard air pneumatic tires feature a layered rubber design filled with air.
Pneumatic tire forklifts are excellent choices for working in locations with uneven or unpaved ground outdoors. Locations that have sharp debris or objects that could puncture a standard air pneumatic tires such as junkyards or lumber yards will benefit from solid resilient pneumatic forklift tires.
Benefits of Cushion Tire Forklifts
Forklifts fitted with cushion tires are a good option for operation on smooth surfaces, both indoor and outdoor. The majority of forklifts that rely on cushion tires are used mostly indoors with limited outdoor use. Warehousing applications and manufacturing facilities often rely on cushion tire forklifts. Warehousing and narrow aisles and tight locations all rely on the benefits of cushion tire forklifts.
Some benefits of using a cushion tire forklift over a pneumatic tire forklift are:
1) Maneuverability
Since cushion tire forklifts do not need to house a larger internal combustion engine, they are more compact and easier to maneuver.
2) Lower Clearance
Forklifts built for indoor use with cushion tires generally have a lower clearance than pneumatic tire equipment, allowing the forklift to more easily navigate doorways and other obstacles such as lights and sprinkler systems.
3) Durability
Durability is a key feature with cushion tire forklift models as they are simple to maintain and offer zero to little risk of being punctured.
4) Quiet
Most cushion tire forklift models use a fuel cell or battery as opposed to an internal combustion engine and are much quieter compared to their diesel or propane counterparts.
5) Environmentally Friendly
Cushion tire forklifts are more environmentally friendly as they use electricity and produce no harmful emissions, compared to internal combustion engine models.
Forklift Tire Choice
Most forklift frames only allow for either a cushion tire or a pneumatic tire. The forklifts’ lifting capacity and frame are specific to the axles and tires in the design. The majority of forklift manufacturers create models to coincide with specific wheels and tires, usually cushion tires or pneumatic tires. Instead of trying to modify the forklift by picking the correct tire for a particular application, it is wiser to choose the forklift that will best suit the job at hand.
Workplace Applications
Suitable Work Applications for Cushion Tires
There are many work applications suitable for using cushion tire forklift models. If most of the transporting, lifting loads and placement happens inside or with limited outdoor use on smooth surfaces, cushion tire forklifts are your best choice.
Forklifts fitted with cushion tires often have a smaller frame and sit much lower to the ground than forklifts fitted with pneumatic tires. This compact design facilitates easier clearance through doorways and overhead obstacle avoidance. However, cushion tire forklifts also have less clearance to the ground which can result in cushion tire forklifts getting easily hung up on outdoor obstacles where the surface is not cleared or even. One solution is to outfit traction tires on the front of the cushion tire forklift. Traction based tires will function in rough terrain environments that have wet surfaces, packed gravel and asphalt. These tires are not recommended for travelling on grass or dirt. Traction tires are utilized on the opposite sides, the steer and drive axles.
One of the top advantages of the cushion forklifts is their tight turning radius. This makes cushion tire forklifts ideal for warehouses and manufacturing facilities that have less space. Areas that are designed with narrow aisles such as warehouse facilities will enjoy the tighter turning radius offered with cushion tire forklift models. Cushion tire forklifts are more cost-effective and available compared to pneumatic tire models.
Suitable Work Applications for Pneumatic Tire Forklifts
Since pneumatic tires contain air, these forklifts are better suited for exterior applications. Pneumatic tires can also be used inside but do not provide the advantages of low clearance, maneuverability or small turning radius. Pneumatic tire forklifts operate with an internal combustion engine and these harmful emissions are dangerous for use indoors. With a wider base and longer frame in comparison to cushion tire models, pneumatic tire forklifts are for use mainly outdoors.
The solid pneumatic tire costs more compared to the air pneumatic tire. This is because a solid pneumatic tire is not susceptible to punctures or gouges because they are made of solid rubber and do not have air in them. These solid pneumatic tires are best for scrap yards and lumber yards where the possibility of running over sharp metal scrap and debris, such as nails, in greatly increased. Air pneumatic tires work great outside on gravel and asphalt applications. The main issue with air pneumatic tires is their ability to become gouged or punctured. Due to their susceptibility for getting gouged or punctured, the work location must be free from sharp debris before driving the air pneumatic tires. Air tires are also known to give a bouncy ride, contributing to operator discomfort and fatigue. It is possible to foam fill the pneumatic forklift tires for a smoother ride. The foam filling option creates a more even ride compared to the solid pneumatic tires or the bounciness of the air-filled pneumatic tires. Foam filling is also used to help prevent flat tires. It takes roughly three days to fill and cure an air pneumatic tire with foam.
Difference in Load Capacity
The load capacity of cushion tire forklifts and pneumatic tire forklifts are about equal. Lift limits are given for certain electric-powered cushion tire forklifts. Pneumatic tire and cushion tire forklifts are available in practically any load capacity. Load capacities come in a wide range - from less than 2,000 pounds to more than 200,000 pounds.
